Asus PRIME B550-PLUS, AMD B550, AM4, ATX, 4 DDR4, HDMI, DP, XFire, PCIe4, M.2

Name: Asus PRIME B550-PLUS, AMD B550, AM4, ATX, 4 DDR4, HDMI, DP, XFire, PCIe4, M.2 - NurdPC
SKU: AUMBB550PLUS-PRIME
Price: 103.08 GBP
Availability: InStock

ASUS

£123.70 Inc. VAT

8 Items sold in last 3 hours

15 People watching this product now!

11 in stock

Additional information

Weight	1.3500 kg
Motherboard Type	Desktop
ATX	Form Factor
Socket	AMD AM4
Chipset	AMD B550
#Hide#DDR Type	DDR4
CPU Support	Click here for CPU support *Note: not compatible with Ryzen 5 3400G & Ryzen 3 3200G CPUs
RAM Technology	DDR4 (Dual Channel)
RAM Slots	4 x DIMM
RAM Speeds	3rd Gen AMD Ryzen CPUs: 4600(O.C)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/3000/2800/2666/2400/2133 MHz Next Ge
Maximum Memory	128GB
Graphics	Integrated Graphics Processor* Graphics specifications may vary between CPU types
Graphics Ports	1 x HDMI 1 x DisplayPort
Multi-GPU Support	Supports AMD 2-Way CrossFireX Technology
PCI/PCI Express	1 x PCIe 4.0 x16 (x16 mode) 1 x PCIe 3.0 x16 (x4 mode) 3 x PCIe 3.0 x1
Storage	6 x SATA III 2 x M.2 (2242/2260/2280/22110) – SATA & PCIe
RAID	RAID 0, 1, 10
Wireless	No
LAN	GB LAN
Audio	Realtek ALC887 7.1-Channel High Definition Audio CODEC
USB Ports Supported	2 x USB 3.2 Gen2 (1 Type-A & 1 Type-C at back) 6 x USB 3.2 Gen1 (4 at back, 2 at mid-board) 6 x USB 2.0 (2 at back, 4 at mid-board)
Back Panel I/O Ports	1 x DisplayPort 1 x HDMI 1 x LAN (RJ45) 2 x USB 3.2 Gen2 (Type-A & Type-C) 4 x USB 3.2 Gen1 (Type-A) 2 x USB 2.0 1 x Optical S/PDIF out 5 x Audio jacks
Internal I/O Connectors	1 x CPU Fan 1 x CPU OPT Fan 3 x Chassis Fan 1 x AIO_PUMP 2 x Aura RGB Strip 1 x Addressable Gen2 1 x USB 3.2 Gen1 2 x USB 2.0 2 x M.2 Socket 3 with M key 1 x SPI TPM 6 x SATA 6Gb/s 1 x Thunderbolt
pa_	7991
Accessories	I/O Shield 2 x SATA 6Gb/s cables 1 x M.2 SSD screw package
Additional Features	See Overview
Package Type	Retail
Package Weight	1.3500 kg
Warranty	3 Years
#Hide#M.2 Slot(s)	Yes (M.2)
#Hide#No. LAN Ports	1 x LAN
#Hide#Max LAN Speed	GB LAN
